Hustler Raptor XDX- 60"

Name: Hustler Raptor XDX- 60"
Brand: Hustler
Availability: OutOfStock

Call for Price

Get a Quote Get Financed Value a Trade Contact Us Book a Demo Get Directions Get Directions Print

The Raptor XDX is at the top of the residential zero-turn category. It has commercial-grade features like a 10-gauge fabricated deck, cast steel deck hangers, vented and toolless removable pulley covers, and reaches up to 8mph with Hydro-Gear® ZT-3100® commercial transmissions. The 5-inch-deep deck allows the XDX to mow through thick grass at top speeds. The heavy-duty XDX is backed by an industry leading 3yr / 300hr warranty and 1yr / 300hr commercial warranty.

21.5hp, 23hp & 24hp Kawasaki Engines
48", 54" & 60” decks
Up to 8 mph mowing speed
3-year / 300 hour limited warranty

Engine	Deck Sizes
21.5HP - Kawasaki FR651	48"
23HP - Kawasaki FR691	54”
24HP - Kawasaki FR730	60"

Specifications

Model

Raptor XDX

Category Name

Zero Turn Mowers

Year

2025

Sale Type

New

Manufacturer

Hustler

features

22" BigBite™ Tires

More aggressive tire to handle tough jobs.

Extra High-back Seat

A premium extra high-back seat with armrests.

Commercial Grade Deck

Heavy-duty 10 gauge steel and 11 gauge front bull nose bumper design for unmatched durability. Up to 60” deck sizes available.

key specs

WARRANTY

3 Year/300 hour residential or 1 Year/300 hour commercial

DRIVE TIRE

22 x 11-10 BigBite™

FRONT TIRE

13 x 6.5

TRANSMISSION

Hydro-Gear ZT-3100®

CUTTING WIDTH

60"

FUEL CAPACITY

3 gal.

CUTTING HEIGHT

1.5" to 4.5"

ENGINE HORSEPOWER

GROUND SPEED (FWD)

Up to 8 mph

ENGINE MANUFACTURER

Kawasaki FR730

engine

COOLING

Air Cooled

DISPLACEMENT

726cc

ENGINE WARRANTY

3 Year Warranty

ENGINE HORSEPOWER

ENGINE MANUFACTURER

Kawasaki FR730

drive system

TYPE

Dual Hydrostatic

TRANSMISSION

Hydro-Gear ZT-3100®

FUEL CAPACITY

3 gal.

PARKING BRAKE

Integrated with steering levers

GROUND SPEED (FWD)

Up to 8 mph

deck

SPINDLES

Aluminum w/1" shaft and sealed ball bearings

DECK LIFT

Foot Operated

DECK DEPTH

BLADE LENGTH

20.50"

CUTTING WIDTH

60"

DECK MATERIAL

Fabricated 10 gauge steel

CUTTING HEIGHT

1.5" to 4.5"

SPINDLE MOUNTS

Reinforced 11 gauge steel

BLADE TIP SPEED

18,400

DECK ENGAGEMENT

Ogura GT1.5

IMPACT TRIM AREA

11 ga. formed channel w/ rolled edge

NUMBER OF BLADES

construction

FRAME

1.5" X 3.0" steel tubing

FRONT AXLE

Fabricated with sealed ball bearings

FRONT CASTER FORK

Fabricated 3/8" steel

FRONT CASTER WHEEL

Sealed ball bearings

general

SEAT

Bolstered extra high-back seat with armrests and built-in lumbar support

CUP HOLDER

dimensions

WEIGHT (LBS)

710

HEIGHT (INCHES)

43.7

LENGTH (INCHES)

71.1

DRIVE TIRE (INCHES)

22 x 11-10 BigBite™

FRONT TIRE (INCHES)

13 x 6.5

WIDTH W/ CHUTE UP (INCHES)

62.2

TIRE-TO-TIRE WIDTH (INCHES)

48.6

PRODUCTIVITY (ACRES PER HOUR)

3.88

dimensions with catcher

CATCHER STYLE

2-bag

CATCHER CAPACITY

7.2 bushel

POWERED / NON-POWERED

Powered

MOWER WIDTH W/ CATCHER

69.2

MOWER LENGTH W/ CATCHER

92.3

literature

Name	Link
Specs PDF	Download
Brochure PDF	Download
